Specifications

CPU

ARM926EJ-S

Up to 900MHz

Neural-network Processing Unit （NPU）

Supports Multiple applications such as object detection/tracking and face detection/recognition

ISP

3A (AWB, AE, AF)

Gamma Correction

Defect Pixel Correction

Lens Shading Correction

Green Balance

3DNR,2DNR

Edge Enhancement

Video Encoder

H.265/H.264 encoder, up to 6MP

JPEG encoder, up to 16384*8192

Supports multi-stream, Video*3 + JPEG*1

Audio Codec

single DAC and single ADC

Supports 8KHz/9.6KHz/11.025KHz/12KHz/16KHz/22.05KHz/24KHz/32KHz/44.1KHz/48KHz Sampling Rate

Supports multiple audio coding/decoding formats

Audio 3A function (AEC, AGC and ANR)

Tsensor

Supports chip temperature monitoring

Security

Supports Security boot

Supports AES/DES/3DES encryption algorithms and AES256 decryption algorithm

Supports RSA2048 decryption algorithm

Supports SHA256 algorithm

Human Interface

Supports DVP/MIPI interface

Compatible with BT.601/BT.656/BT.1120 standard

Supports Bayer RAW data and YUV422 data

Supports dual-CIS input

SAR ADC with three channels

Peripherals

USB2.0

Ethernet MAC and PHY

MMC/SD/SDIO

SPI

TWI

I2S

UART

GPIO

PWM

Memory

Embedded 512Mbit/1Gbit  DDR2

Package

QFN88, 9mm x 9mm x 0.9mm
